Infitek Negative Pressure Laboratory Chemical Diaphragm Vacuum Pump Vacp-D31

Customization: Available
After-sales Service: Online Support,Video Technical Support
Warranty: 2 Year

Product Description

Diaphragm Vacuum Pump Overview
Negative Pressure Laboratory Chemical Diaphragm Vacuum Pump VACP-D31
Basic Information
Model NO.
VACP-D31
Structure
Rotary Vacuum Pump
Vacuum Degree
High Vacuum
Working Conditions
Dry
Pumping Speed
20 L/Min
Ultimate Vacuum
200mbar
Pressure
Negative Pressure
Dimension
270X130X210 mm
Weight
7 Kg
Power
160 W
Noise
<60 dB
Origin
China
Key Features
  • Oil-Free & Pollution-Free: No working medium needed, ensuring a clean environment with integrated filter materials.
  • Advanced Production: Utilizes new technology and materials for smooth movement and high air flow rates.
  • Safety Protection: Equipped with an overheating power-off protector that activates at 130°C to prevent motor damage.
  • Corrosion Resistance: Frictionless film movement with imported rubber diaphragms for long-lasting durability.
  • Continuous Operation: Features an automatic cooling and exhaust system designed for 24-hour non-stop work.
  • Adjustable Design: Pressure is adjustable to meet specific vacuum and gas flow requirements.
  • Low Noise Operation: High-quality imported bearings ensure stable and quiet working efficiency.
  • Compact & Portable: Small size and light weight, ideal for saving laboratory space and easy maintenance.
Technical Specifications
Model: VACP-D31
Pumping Speed (L/Min) 20 Pump Head 1
Ultimate Vacuum 200mbar Body Temp (°C) <55
Voltage 220Vac, 50Hz Dimension (mm) 270x130x210
Power 160W Weight (Kg) 7
Air Inlet (mm) φ6 Diaphragm Imported Rubber
Air Outlet (mm) Silencer Cotton Valve Plate Imported Rubber
Ambient Temp (°C) 7-40 Noise (dB) <60
Packaging & Certifications
Packaging and Shipping
Certifications
Production Showcase
Production Process
Laboratory Equipment Factory
Quality Inspection
Frequently Asked Questions
How is the quality of the vacuum pumps?
All products comply with CE standards. We have an independent quality inspection team conducting multiple inspections from parts supply to dispatch. Third-party testing services like SGS, BV, and TUV are also available.
What are the pre- and after-sales services?
We provide timely replies to all enquiries and real-time manufacturing updates. After-sales support includes contracted maintenance in over 60 countries and guaranteed parts supply for at least 10 years.
Is OEM service available?
Yes, most products are available for OEM customization, including logos, packaging, and specific functional adjustments.
What is the typical lead time?
For stocked products, the lead time is approximately 7-15 days. For non-stocked or custom items, manufacturing typically takes around 20 days.
Does the pump require oil for operation?
No, this is a dry diaphragm vacuum pump. It does not require any working medium or oil, ensuring a pollution-free operation ideal for chemical laboratory environments.
Is the pump suitable for continuous 24-hour use?
Yes, the pump is designed with an automatic cooling and exhaust system that allows for continuous operation for up to 24 hours.
