Impeller Number
Multistage Pump
Working Pressure
Middle Pressure Pump
Influent Type
Single Suction Pump
Pump Shaft Position
Vertical Pump
Casing Combined
Verticaljoint Surface Pump
Mounting Height
Suction Centrifugal
Production Capacity
100000PCS/Year
📍
Submersible Depth: 5m
🌡️
Liquid Temperature: Up to 40ºC
🌍
Ambient Temperature: Up to 40ºC
⚙️
Solid Grain Diameter: Less than 10mm
🔗
Connection: Thread, Flange
🔋
Winding: Copper Winding
Structural Characteristics
Casing: Stainless steel casing
Shaft Seal: Double shaft seal
Insulation Class: F
Protection Class: IP68
Impeller Type: Open impeller
Frequently Asked Questions
Q1: What is the maximum submersible depth for this pump?
The pump is designed for a maximum submersible depth of 5 meters.
Q2: Can the pump handle liquids at high temperatures?
The pump can safely handle liquid temperatures up to 40ºC.
Q3: What material is used for the pump casing?
The pump features a durable stainless steel casing for enhanced corrosion resistance.
Q4: What size of solids can pass through the pump?
The pump allows solid grains with a maximum diameter of less than 10mm to pass through.
Q5: What is the protection rating of this motor?
The motor is built to IP68 protection standards with Class F insulation.
Q6: What power frequencies are supported?
This pump supports both 50Hz and 60Hz power frequencies for versatile application.
